SIG-5441 – 4-Port Digital Input I/O Gateway to Sollae Cloud

SIG-5441 is a remote I/O gateway with 4 digital inputs for monitoring equipment and sensor ON/OFF states. It connects securely to Sollae Cloud via MQTT over TLS, so you can monitor inputs anywhere through a web interface. Each input also supports counting, making it suitable for both state monitoring and pulse/counting applications.

4× Digital Inputs
Dry/Wet contact + NPN/PNP
Counter Function
Per-input counting
Sollae Cloud
Multi-user access + web UI
MQTT over TLS
Secure cloud connectivity
SIG-5441

Key features of the SIG-5441

  • • Monitor 4 digital input channels via Sollae Cloud web interface (PC/tablet/smartphone).
  • • Counter function on each input for counting pulses/events.
  • • Threshold & state-change events can trigger alerts in the web UI.
  • • Can send commands to control digital outputs on other devices (e.g., SIG-5451, SIG-5601) based on your rules.
  • • Customizable web UI for monitoring with Sollae Studio.

Cloud monitoring + event-driven automation

SIG-5441 is designed for quick deployment: connect it to the Internet, register it in Sollae Cloud, and start monitoring. Create your own events (state changes, counter thresholds) and use them to alert operators and trigger actions.

  • • Real-time monitoring and multi-user access via cloud.
  • • Create user-defined events and alarms (threshold/state-change driven).
4 digital inputs
Monitor switches, relays, sensors and ON/OFF signals remotely.
Counting applications
Use counters for pulses, production counts, door events, and more.
MQTT over TLS
Secure connection to Sollae Cloud.
Cloud web interface
Access from anywhere with multi-user support.
Events & alarms
Trigger alerts and actions when inputs change or counters hit thresholds.
Sollae Studio UI
Customize dashboards and monitoring pages.

Digital Input

Input Type

Dry Contact / Wet Contact / NPN / PNP

Input Voltage Range

4.5V ~ 25V

Number of Ports

4 ports

Network Physical Interface

Network Interface

10Base-T/100Base-Tx Ethernet(RJ45)
Ethernet Speed Auto Sense
1:1 or Cross-over Cable Auto Sense
1000 VAC Isolation

Software Functions

Protocols

IPv4/IPv6 Dual Stack
TCP/UDP
ICMP, DHCP, mDNS, TLS, MQTT
SSL/TLS

Indicators

LED

MTX, MRX, Di0, Di1, Di2, Di3

Management

spFinder

Configuration and Monitoring Tool

Security

Password

Dimension

Size

94mm x 57mm x 23mm

Weight

about 65g

Operating Environment

Input Voltage

DC 5±0.5V

Protection

Reverse Voltage Protection / Surge Protection

Current Consumption

typically, 150mA

Operating Temperature

-40℃ ~ +85℃

Storage Temperature

-40℃ ~ +85℃

Certificate

KC

Registration(KN 32, KN 35)

CE

EMC 2014/30/EU, RoHS 2011/65/EU

FCC

FCC Part 15 Subpart B, Class A
